Bake Text

TEXT

available with license

Bakes text. Creates a new layer if it does not exist. Can apply multiple texts to multiple planes, with different fonts, sizes, and alignments.

INPUTS

• text : String values for each text object.

• planes : Planes or Point locations for text objects. Points will be converted to XY planes.

• font : Font. Multiple fonts can be used if you have one font per plane.

• size : Size. Multiple sizes can be used if you have one size per plane.

• alignment : Justification. Multiple justifications can be used if you have one justification per plane. top: 0=left 1=mid 2=right | mid: 3=left 4=mid 5=right | bottom: 6=left 7=mid 8=right Default=0.

• layer : Layer to bake text objects to. One layer per data tree branch. Default = ‘ANNO::TEXT’

• color : Color to set the layer to if creating a new layer. Default = White

• bakename : Name to use if you want to overwrite specific text objects. One name per data tree branch.

• bake : Will activate baking the text objects. Use a button or a boolean value.

---
